| Onderdeel nummer | WF57STIACDNN0 |
| Merk | Winstar |
| Maat | 5.7 |
| Sollicitatie | Industrial |
| Oplossing | 320×240 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | Grayscale |
| Tegenlicht | WLED |
| Koppel | 8/16-bit |
| paneel merk | Winstar |
| paneel grootte | 5.7" |
| oplossing | 320×240, QVGA, 70PPI |
| weergavegebied | 115.2(W)×86.4(H) mm |
| omtrek grootte | 160(W)×109(H) ×7.5(D) mm |
| helderheid | 1000 cd/m² (Typ.) |
| kijk hoek | - |
| beste zicht op | 12 o'clock |
| kleuren weergeven | Grayscale |
| frequentie | - |
| paneel gewicht | - |
| signaal interface | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| paneelmodel | WF57STIACDNN0 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | Rectangle |
| omlijsting openen | 122.0(W)×92.0(H) mm |
| oppervlak | Glare (Haze 0%) |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | - |
| soort lamp | WLED , Without Driver |
| touch screen | Without |
| sollicitatie | Industrial |
