| Onderdeel nummer | WEO009664AL |
| Merk | Winstar |
| Maat | 0.95 |
| Sollicitatie | Wearable MP3 PMP |
| Oplossing | 96×64 |
| Samenstelling | PM-OLED, OLED |
| Helderheid | |
| CR | |
| Kleuren | Mono(Yellow) |
| Tegenlicht | self |
| Koppel | 8-bit |
| merk | Winstar |
| model | WEO009664AL |
| diagonale maat | 0.95 inch |
| type | PM-OLED, OLED |
| pixel formaat | 96×64 121PPI |
| configuratie | Rectangle |
| actief gebied | 19.946(H)×13.418(V) mm |
| omtrek afm. | 24.9(H)×22.95(V) ×1.95(D) mm |
| bezel gebied | 21.953(H)×15.424(V) mm |
| behandeling | - |
| richting bekijken | Symmetry |
| reactietijd | - |
| kijk hoek | - |
| bedrijfsmodus | - |
| ondersteunende kleur | Mono(Yellow) |
| lichtbron | self |
| gewicht | - |
| ontworpen voor | Wearable MP3 PMP |
| frame rate | - |
| aanraakpaneel | Without |
| d-ic detail | COG Built-in SSD1305Z |
| interface-type | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 25 pins FPC |
| stroomvoorziening | 3.0V (Typ.) |
| omgeving | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
