| Onderdeel nummer | WEF012864QS |
| Merk | Winstar |
| Maat | 2.7 |
| Sollicitatie | Home Appliance Handh |
| Oplossing | 128×64 |
| Samenstelling | PM-OLED , OLED |
| Helderheid | |
| CR | |
| Kleuren | Mono(Blue) |
| Tegenlicht | self |
| Koppel | 8-bit |
| paneel merk | Winstar |
| paneel grootte | 2.7" |
| oplossing | 128×64, 52PPI |
| weergavegebied | 61.41(W)×30.69(H) mm |
| omtrek grootte | 89.7(W)×47.2(H) mm |
| kijk hoek | - |
| beste zicht op | Symmetry |
| kleuren weergeven | Mono(Blue) |
| frequentie | - |
| bestuurder ic | COG Built-in SSD1309ZC |
| paneel gewicht | - |
| signaal interface | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| ingangsspanning | 3.0/13V (Typ.)(VDD/VCC) |
| omgeving | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 80 °C |
| paneelmodel | WEF012864QS |
| paneel type | PM-OLED , OLED |
| pixel formaat | Rectangle |
| omlijsting openen | 63.41(W)×32.69(H) mm |
| oppervlak | - |
| weergavemodus | - |
| reactietijd | - |
| soort lamp | self |
| touch screen | Without |
| sollicitatie | Home Appliance Handheld & PDA Healthcare Instruments & Meters |
