| Onderdeel nummer | V650HP1-LS6 Rev.E8 |
| Merk | Innolux |
| Maat | 65 |
| Sollicitatie | TV Sets |
| Oplossing | 1920×1080 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 5000:1 |
| Kleuren | 1.07B |
| Tegenlicht | 4 |
| Koppel | LVDS |
| fabrikant | Innolux |
| modelnaam | V650HP1-LS6 Rev.E8 |
| scherm grootte | 65 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 34PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 1428.48 × 803.52 (H×V) |
| overzicht (mm) | 1450.5 × 828.52 × 30.8 (H×V×D) |
| bezel gebied (mm) | 1435.5 × 810.52 (H×V) |
| behandeling | Antiglare (Haze 1%), Hard coating (3H) |
| luminantie | 350 cd/m² (Typ.) |
| contrast ratio | 5000 : 1 (Typ.) (TM) |
| kijk hoek | 88/88/88/88 (Typ.)(CR≥20) |
| antwoord | 6.5 (Typ.)(G to G) ms |
| goed zicht op | Symmetry |
| werk modus | Super MVA, Normally Black, Transmissive |
| kleuren diepte | 1.07B 100% sRGB |
| tegenlicht | 4 strings WLED , 30K hours , With LED Driver |
| massa | 23.0±1.2Kgs |
| gebruikt voor | TV Sets |
| vernieuwingsfrequentie | 120Hz |
| touch screen | Without |
| signaal type | LVDS (4 ch, 10-bit) , Connector 102 pins |
| spanningsvoorziening | 12.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
