| Onderdeel nummer | V650HP1-LS6 Rev.E4 |
| Merk | Chimei Innolux |
| Maat | 65 |
| Sollicitatie | TV Sets |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 5000:1 |
| Kleuren | 1.07B |
| Tegenlicht | WLED |
| Koppel | |
| merk | Chimei Innolux |
| model | V650HP1-LS6 Rev.E4 |
| diagonale maat | 65 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1920(RGB)×1080 [FHD] 34PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 1428.48(H)×803.52(V) mm |
| omtrek afm. | - |
| luminantie | - |
| contrast ratio | 5000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 6.5 (Typ.)(G to G) |
| kijk hoek | 88/88/88/88 (Typ.)(CR≥20) |
| bedrijfsmodus | Super MVA, Normally Black, Transmissive |
| ondersteunende kleur | 1.07B |
| lichtbron | WLED |
| gewicht | - |
| ontworpen voor | TV Sets |
| frame rate | - |
| aanraakpaneel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| HV650QUB-B00 | BOE | 65 | 3840×2160 |
| LC650DUF-FGA2 | LG Display | 65 | 1920×1080 |
| LC650DUF-FGF1 | LG Display | 65 | 1920×1080 |
| P650HVN02.6 | AUO | 65 | 1920×1080 |
| T645HW02 V5 | AUO | 65 | 1920×1080 |
| T645HW04 V0 CELL | AUO | 65 | 1920×1080 |
| T650HVJ02.1 | AUO | 65 | 1920×1080 |
| V650HP1-LS6 | Innolux | 65 | 1920×1080 |
| V650HP1-LS6 Rev.E | Innolux | 65 | 1920×1080 |
