| Onderdeel nummer | V400HJ6-PE1 Rev.CA |
| Merk | Innolux |
| Maat | 40 |
| Sollicitatie | TV Sets |
| Oplossing | 1920×1080 |
| Samenstelling | CELL, a-Si TFT-LCD |
| Helderheid | |
| CR | 5000:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | LVDS |
| fabrikant | Innolux |
| modelnaam | V400HJ6-PE1 Rev.CA |
| scherm grootte | 40 inch |
| scherm type | CELL, a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 55PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 878.112 × 485.352 (H×V) |
| overzicht (mm) | 888.392 × 494.152 × 1.29 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare (Haze 1%), Hard coating (3H) |
| luminantie | 0 cd/m² |
| contrast ratio | 5000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 8.5 (Typ.)(G to G) ms |
| goed zicht op | Symmetry |
| werk modus | MVA, Normally Black, Transmissive |
| glas dikte | 0.50+0.50 mm |
| doorlaatbaarheid | 5.5% (Typ.)(with Polarizer) |
| kleuren diepte | 16.7M 72% NTSC |
| tegenlicht | No B/L |
| massa | 1.40±0.07Kgs |
| gebruikt voor | TV Sets |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| driver ic lijst | Built-in COF 8 source + 4 gate chips |
| signaal type | LVDS (2 ch, 8-bit) , Connector 51 pins |
| spanningsvoorziening | 12.0V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LTA400HL15 | Samsung | 40 | 1920×1080 |
| LTA400HM01 | Samsung | 40 | 1920×1080 |
| LTA400HM13 | Samsung | 40 | 1920×1080 |
| LTI400HA02 | Samsung | 40 | 1920×1080 |
| T400HW03 V0 | AUO | 40 | 1920×1080 |
| T400HW04 V2 | AUO | 40 | 1920×1080 |
| T400XW01 V6 | AUO | 40 | 1366×768 |
| V400DK1-KE1 | Innolux | 40 | 3840×2160 |
| V400DK2-KS5 | Innolux | 40 | 3840×2160 |
| V400HJ6-PE1 | Innolux | 40 | 1920×1080 |
