| Onderdeel nummer | TX18D210VM0BAA |
| Merk | KOE |
| Maat | 7.0 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 800×480 |
| Samenstelling | LCM , LTPS TFT-LCD |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | Parallel |
| fabrikant | KOE |
| scherm grootte | 7.0 inch |
| pixel nummer | 800(RGB)×480 (WVGA) 133PPI |
| actief gebied (mm) | 152.4 × 91.44 (H×V) |
| bezel gebied (mm) | 156.2 × 94.5 (H×V) |
| luminantie | 800 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 262K 72% NTSC |
| massa | 214g (Typ.) |
| vernieuwingsfrequentie | 60Hz |
| signaal type | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| modelnaam | TX18D210VM0BAA |
| scherm type | LCM , LTPS TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 167.7 × 109.5 × 20.3 (H×V×D) |
| behandeling | - |
| contrast ratio | 1200 : 1 (Typ.) (TM) |
| antwoord | 30 (Typ.)(Tr+Td) ms |
| werk modus | IPS, Normally Black, Transmissive |
| tegenlicht | WLED , 50K hours , With LED Driver |
| gebruikt voor | Industrial Outdoor High Brightness Automotive Display |
| touch screen | Without |
