| Onderdeel nummer | TPM0501010P |
| Merk | JDI |
| Maat | 5.0 |
| Sollicitatie | Mobile Phone |
| Oplossing | 1080×1920 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | MIPI |
| merk | JDI |
| model | TPM0501010P |
| diagonale maat | 5.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 1080(RGB)×1920 [FHD] 445PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 61.641(H)×109.584(V) mm |
| omtrek afm. | 64.04(H)×116.52(V) ×1.48(D) mm |
| luminantie | 450 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| richting bekijken | Symmetry |
| reactietijd | 25 (Typ.)(Tr+Td) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| bedrijfsmodus | IPS, Normally Black, Transmissive |
| ondersteunende kleur | 16.7M 85% NTSC |
| lichtbron | WLED [7S2P] , W/O Driver |
| gewicht | TBD |
| ontworpen voor | Mobile Phone |
| frame rate | 60Hz |
| aanraakpaneel | In-Cell Touch |
| interface-type | MIPI (4 data lanes) , 40 pins Connector |
| stroomvoorziening | 1.8/5.5/-5.5V (Typ.)(IOVCC/AVDD/AVEE) |
| omgeving | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
