| Onderdeel nummer | TM150TDSG80 |
| Merk | TIANMA |
| Maat | 15.0 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| paneel merk | TIANMA |
| paneelmodel | TM150TDSG80 |
| paneel grootte | 15.0" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1024(RGB)×768, XGA, 85PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 304.128(W)×228.096(H) mm |
| omlijsting openen | 307.4(W)×231.3(H) mm |
| omtrek grootte | 326.5(W)×253.5(H) ×10(D) mm |
| oppervlak | Antiglare |
| helderheid | 350 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| weergavemodus | TN, Normally White, Transmissive |
| beste zicht op | 12 o'clock |
| reactietijd | 8 (Typ.)(Tr+Td) |
| kleuren weergeven | 262K/16.7M 60% NTSC |
| soort lamp | WLED , 30K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | TBD |
| sollicitatie | Industrial |
| signaal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -10 ~ 65 °C ; Storage Temp.: -20 ~ 65 °C |
