| Onderdeel nummer | TM116VDSP03 |
| Merk | TIANMA |
| Maat | 11.6 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 900:1 |
| Kleuren | 16.7M |
| Tegenlicht | 9S6P |
| Koppel | LVDS |
| fabrikant | TIANMA |
| modelnaam | TM116VDSP03 |
| scherm grootte | 11.6 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 190PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 256.32 × 144.18 (H×V) |
| overzicht (mm) | 273.5 × 166.5 × 11.5 (H×V×D) |
| bezel gebied (mm) | 259.31 × 148.73 (H×V) |
| behandeling | Hard coating |
| luminantie | 1000 cd/m² (Typ.) |
| contrast ratio | 900 : 1 (Typ.) (TM) |
| kijk hoek | 88/88/88/88 (Typ.)(CR≥10) |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | SFT, Normally Black, Transmissive |
| kleuren diepte | 16.7M 70% NTSC |
| tegenlicht | 9S6P WLED , 50K hours , No Driver |
| massa | TBD |
| gebruikt voor | Industrial Outdoor High Brightness |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningsvoorziening | 3.3/10.7/20/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| max. waarderingen | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
