| Onderdeel nummer | TM104TDGP10 |
| Merk | TIANMA |
| Maat | 10.4 |
| Sollicitatie | Industrial |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | 8S4P |
| Koppel | LVDS |
| paneel merk | TIANMA |
| paneel grootte | 10.4" |
| oplossing | 1024(RGB)×768, XGA, 123PPI |
| weergavegebied | 210.432(W)×157.824(H) mm |
| omtrek grootte | 230(W)×175.8(H) ×9.06(D) mm |
| helderheid | 450 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 262K/16.7M 50% NTSC |
| frequentie | 60Hz |
| paneel gewicht | 430g (Typ.) |
| signaal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| paneelmodel | TM104TDGP10 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 213.43(W)×160.82(H) mm |
| oppervlak | Antiglare |
| contrast ratio | 1200:1 (Typ.) (TM) |
| weergavemodus | SFT, Normally Black, Transmissive |
| reactietijd | 35 (Typ.)(Tr+Td) |
| soort lamp | 8S4P WLED , With LED Driver |
| touch screen | Without |
| sollicitatie | Industrial |
