| Onderdeel nummer | TM101DDHG04 |
| Merk | TIANMA |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | 10S3P |
| Koppel | |
| paneel merk | TIANMA |
| paneel grootte | 10.1" |
| oplossing | 1024(RGB)×600, WSVGA, 117PPI |
| weergavegebied | 222.72(W)×125.28(H) mm |
| omtrek grootte | 233.1(W)×137.1(H) ×3.3(D) mm |
| helderheid | 300 cd/m² (Typ.) |
| kijk hoek | 80/80/75/80 (Typ.)(CR≥10) |
| beste zicht op | 12 o'clock |
| kleuren weergeven | 262K/16.7M 47% NTSC |
| frequentie | 60Hz |
| gewicht | 210/220g (Typ./Max.) |
| paneelmodel | TM101DDHG04 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 225.72(W)×128.28(H) mm |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 7/9 (Typ.)(Tr/Td) |
| soort lamp | 10S3P WLED , 15K hours , Without Driver |
| touch screen | Without |
| sollicitatie | Industrial |
