| Onderdeel nummer | TM089CFSP01 |
| Merk | TIANMA |
| Maat | 8.9 |
| Sollicitatie | 3D Printer |
| Oplossing | 3840×2400 |
| Samenstelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 800:1 |
| Kleuren | Monochrome |
| Tegenlicht | No |
| Koppel | |
| paneel merk | TIANMA |
| paneel grootte | 8.9" |
| oplossing | 3840×2400, 508PPI |
| weergavegebied | 192(W)×120(H) mm |
| omtrek grootte | 202(W)×133(H) ×1.24(D) mm |
| helderheid | 0 cd/m² |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| glas diepte | - |
| kleuren weergeven | Monochrome |
| frequentie | 60Hz |
| gewicht | TBD |
| paneelmodel | TM089CFSP01 |
| paneel type | a-Si TFT-LCD , CELL |
| pixel formaat | Rectangle |
| omlijsting openen | - |
| oppervlak | Clear |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | SFT, Normally Black, Transmissive |
| reactietijd | 25 (Typ.)(Tr+Td) |
| doorlaatbaarheid | 5.4% (Typ.)(with Polarizer) |
| soort lamp | No B/L |
| touch screen | Without |
| sollicitatie | 3D Printer |
| A089SW01 V0 | AUO | 8.9 | 1024×600 |
| HSD089IFW1-B00 | HannStar | 8.9 | 1024×600 |
| HSD089IFW3-A00 | HannStar | 8.9 | 1024×600 |
| HT089WX1-100 | HYDIS | 8.9 | 1280×768 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| KCG089HV1AA-G00 | Kyocera | 8.9 | 640×240 |
| LP089WS1-TLA1 | LG Display | 8.9 | 1024×600 |
| LP089WS2-TLB1 | LG Display | 8.9 | 1024×600 |
| LSUGC202XA | ALPS | 8.9 | 640×240 |
| NL12876BC15-01 | NLT | 8.9 | 1280×768 |
