| Onderdeel nummer | TM080RDHG30 |
| Merk | TIANMA |
| Maat | 8.0 |
| Sollicitatie | Industrial |
| Oplossing | 800×480 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | 3S12P |
| Koppel | |
| paneel merk | TIANMA |
| paneel grootte | 8.0" |
| oplossing | 800(RGB)×480, WVGA, 116PPI |
| weergavegebied | 176.64(W)×99.36(H) mm |
| helderheid | 450 cd/m² (Typ.) |
| kijk hoek | 70/70/60/70 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K/16.7M |
| frequentie | 60Hz |
| gewicht | - |
| paneelmodel | TM080RDHG30 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 25 (Typ.)(Tr+Td) |
| soort lamp | 3S12P WLED , 20K hours , Without Driver |
| touch screen | Without |
| sollicitatie | Industrial |
