| Onderdeel nummer | TM070RDHG25 |
| Merk | TIANMA |
| Maat | 7.0 |
| Sollicitatie | Industrial |
| Oplossing | 800×480 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 262K |
| Tegenlicht | 3S8P |
| Koppel | |
| paneel merk | TIANMA |
| paneel grootte | 7.0" |
| oplossing | 800(RGB)×480, WVGA, 134PPI |
| weergavegebied | 154.08(W)×85.92(H) mm |
| omtrek grootte | 164.9(W)×100(H) ×8.1(D) mm |
| helderheid | 450 cd/m² (Typ.) |
| kijk hoek | 80/80/60/80 (Typ.)(CR≥10) |
| beste zicht op | 6 o'clock |
| kleuren weergeven | 262K 50% NTSC |
| frequentie | 60Hz |
| gewicht | TBD |
| paneelmodel | TM070RDHG25 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | 157.08(W)×89.39(H) mm |
| oppervlak | Antiglare |
| contrast ratio | 1000:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 15 (Typ.)(Tr+Td) |
| soort lamp | 3S8P WLED , 20K hours , Without Driver |
| touch screen | Without |
| sollicitatie | Industrial |
