| Onderdeel nummer | TM070RDHG12 |
| Merk | TIANMA |
| Maat | 7.0 |
| Sollicitatie | Portable DVD Player |
| Oplossing | 800×480 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | Parallel |
| merk | TIANMA |
| model | TM070RDHG12 |
| diagonale maat | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 800(RGB)×480 [WVGA] 134PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 154.08(H)×85.92(V) mm |
| omtrek afm. | 164.9(H)×100(V) ×6(D) mm |
| bezel gebied | 157.08(H)×89.39(V) mm |
| behandeling | Antiglare |
| luminantie | 350 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| richting bekijken | 12 o'clock |
| reactietijd | 20 (Typ.)(Tr+Td) |
| kijk hoek | 70/70/60/70 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 262K/16.7M 50% NTSC |
| lichtbron | WLED [3S7P] , 20K hours , W/O Driver |
| gewicht | 165g (Typ.) |
| ontworpen voor | Portable DVD Player Digital Photo Frame |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| interface-type | Parallel RGB (1 ch, 6/8-bit) , 60 pins FPC |
| stroomvoorziening | 3.3/10.6/10.6/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| omgeving | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| TM070DDH09 | Tianma | 7.0 | 1024×600 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070SDH03 | Tianma | 7.0 | 800×600 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
