| Onderdeel nummer | TM070DVHG01-41 |
| Merk | TIANMA |
| Maat | 7.0 |
| Sollicitatie | Industrial |
| Oplossing | 1024×600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 16.7M |
| Tegenlicht | 3S6P |
| Koppel | |
| paneel merk | TIANMA |
| paneel grootte | 7.0" |
| oplossing | 1024(RGB)×600, WSVGA, 169PPI |
| weergavegebied | 153.6(W)×90(H) mm |
| omtrek grootte | 171.5(W)×110.3(H) ×5.3(D) mm |
| helderheid | 270 cd/m² (Typ.) |
| kijk hoek | 75/75/70/75 (Typ.)(CR≥10) |
| beste zicht op | 12 o'clock |
| kleuren weergeven | 16.7M 50% NTSC |
| frequentie | 60Hz |
| gewicht | - |
| paneelmodel | TM070DVHG01-41 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | - |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 20 (Typ.)(Tr+Td) |
| soort lamp | 3S6P WLED , 20K hours , Without Driver |
| touch screen | PCAP |
| sollicitatie | Industrial |
