| Onderdeel nummer | TM043NDHG21 |
| Merk | TIANMA |
| Maat | 4.3 |
| Sollicitatie | Handheld & PDA P |
| Oplossing | 480×272 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 900:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| merk | TIANMA |
| model | TM043NDHG21 |
| diagonale maat | 4.3 inch |
| type | a-Si TFT-LCD, LCM |
| pixel formaat | 480(RGB)×272 [WQVGA] 128PPI |
| configuratie | RGB Vertical Stripe |
| actief gebied | 95.04(H)×53.856(V) mm |
| omtrek afm. | 105.5(H)×67.2(V) ×3.2(D) mm |
| bezel gebied | 99.04(H)×54.86(V) mm |
| behandeling | Glare (Haze 0%), Hard coating (3H) |
| luminantie | 400 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| richting bekijken | 12 o'clock |
| reactietijd | 20 (Typ.)(Tr+Td) |
| kijk hoek | 80/80/80/60 (Typ.)(CR≥10) |
| bedrijfsmodus | TN, Normally White, Transmissive |
| ondersteunende kleur | 16.7M 54% NTSC |
| lichtbron | WLED [5S2P] , 50K hours , W/O Driver |
| gewicht | TBD |
| ontworpen voor | Handheld & PDA Portable Navigation |
| frame rate | 60Hz |
| aanraakpaneel | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
