| Onderdeel nummer | TM028HDZ58 |
| Merk | TIANMA |
| Maat | 2.8 |
| Sollicitatie | Mobile Phone |
| Oplossing | 240×320 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 65K/262K |
| Tegenlicht | 1S4P |
| Koppel | Parallel |
| fabrikant | TIANMA |
| modelnaam | TM028HDZ58 |
| scherm grootte | 2.8 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 240(RGB)×320 (QVGA) 141PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 43.2 × 57.6 (H×V) |
| overzicht (mm) | - |
| luminantie | - |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| kijk hoek | 60/60/60/50 (Typ.)(CR≥10) |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| goed zicht op | 6 o'clock |
| werk modus | TN, Normally White, Transmissive |
| kleuren diepte | 65K/262K 55% NTSC |
| tegenlicht | 1S4P WLED , No Driver |
| massa | - |
| gebruikt voor | Mobile Phone |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | Parallel RGB (1 ch, 6-bit) + SPI |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
