| Onderdeel nummer | TM024HDHG04 |
| Merk | TIANMA |
| Maat | 2.4 |
| Sollicitatie | Handheld & PDA |
| Oplossing | 240×320 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | - |
| Tegenlicht | WLED |
| Koppel | CPU |
| paneel merk | TIANMA |
| paneelmodel | TM024HDHG04 |
| paneel grootte | 2.4" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 240(RGB)×320, QVGA, 166PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 36.72(W)×48.96(H) mm |
| omlijsting openen | - |
| helderheid | - |
| contrast ratio | 500:1 (Typ.) (TM) |
| kijk hoek | 70/70/70/60 (Typ.)(CR≥10) |
| weergavemodus | TN, Normally White, Transmissive |
| beste zicht op | - |
| reactietijd | 20 (Typ.)(Tr+Td) |
| kleuren weergeven | |
| soort lamp | WLED |
| frequentie | - |
| touch screen | Without |
| paneel gewicht | - |
| sollicitatie | Handheld & PDA |
| signaal interface | CPU FPC |
| omgeving | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
