| Onderdeel nummer | TL055BDXP03 |
| Merk | TIANMA |
| Maat | 5.5 |
| Sollicitatie | Mobile Phone |
| Oplossing | 1440×2560 |
| Samenstelling | LCM , LTPS TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 16.7M |
| Tegenlicht | 5S3P |
| Koppel | MIPI |
| fabrikant | TIANMA |
| scherm grootte | 5.5 inch |
| pixel nummer | 1440(RGB)×2560 (Quad-HD) 537PPI |
| actief gebied (mm) | 68.04 × 120.96 (H×V) |
| luminantie | - |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M 70% NTSC |
| massa | TBD |
| vernieuwingsfrequentie | 70Hz |
| signaal type | MIPI (2 ch, 4 data lanes) , 50 pins Connector |
| spanningsvoorziening | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| max. waarderingen | Storage Temp.: -30 ~ 70 °C Operating Temp.: -30 ~ 60 °C |
| modelnaam | TL055BDXP03 |
| scherm type | LCM , LTPS TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 70.94 × 128.29 × 1.46 (H×V×D) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| antwoord | 8 (Typ.)(Tr+Td) ms |
| werk modus | SFT, Normally Black, Transmissive |
| tegenlicht | 5S3P WLED |
| gebruikt voor | Mobile Phone |
| touch screen | Without |
