| Onderdeel nummer | TFTMD089061 |
| Merk | JDI |
| Maat | 8.9 |
| Sollicitatie | Pad & Tablet |
| Oplossing | 2560×1600 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 16.7M |
| Tegenlicht | 6S6P |
| Koppel | |
| paneel merk | JDI |
| paneel grootte | 8.9" |
| oplossing | 2560(RGB)×1600, WQXGA, 338PPI |
| weergavegebied | 192(W)×120(H) mm |
| omtrek grootte | 200.3(W)×132.1(H) ×3.55(D) mm |
| helderheid | 500 cd/m² (Typ.) |
| kijk hoek | - |
| beste zicht op | Symmetry |
| kleuren weergeven | 16.7M |
| frequentie | 60Hz |
| gewicht | 78.0g (Typ.) |
| paneelmodel | TFTMD089061 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | Hard coating |
| contrast ratio | 1200:1 (Typ.) (TM) |
| weergavemodus | IPS, Normally Black, Transmissive |
| reactietijd | - |
| soort lamp | 6S6P WLED , Without Driver |
| touch screen | Without |
| sollicitatie | Pad & Tablet |
