| Onderdeel nummer | TCG121XGLPBPNN-AN40-S |
| Merk | Kyocera |
| Maat | 12.1 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1024×768 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 600:1 |
| Kleuren | 262K/16.2M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| paneel merk | Kyocera |
| paneelmodel | TCG121XGLPBPNN-AN40-S |
| paneel grootte | 12.1" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1024(RGB)×768, XGA, 105PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 245.76(W)×184.32(H) mm |
| omlijsting openen | 249.0(W)×187.5(H) mm |
| omtrek grootte | 260.5(W)×203(H) ×10.9(D) mm |
| oppervlak | Antiglare |
| helderheid | 780 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | AWV, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 18/12 (Typ.)(Tr/Td) |
| kleuren weergeven | 262K/16.2M 51% NTSC |
| soort lamp | WLED , 50K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | 555g |
| sollicitatie | Industrial Outdoor High Brightness |
| signaal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
