| Onderdeel nummer | T550QVR08.4 CELL |
| Merk | AUO |
| Maat | 55 |
| Sollicitatie | TV Sets |
| Oplossing | 3840×2160 |
| Samenstelling | a-Si TFT-LCD , CELL |
| Helderheid | |
| CR | 3500:1 |
| Kleuren | 1.07B |
| Tegenlicht | No |
| Koppel | V-by-One |
| merk | AUO |
| diagonale maat | 55 inch |
| pixel formaat | 3840(RGB)×2160 [UHD] 80PPI |
| actief gebied | 1209.6(H)×680.4(V) mm |
| bezel gebied | - |
| luminantie | 0 cd/m² |
| richting bekijken | Symmetry |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| plaatdikte | - |
| ondersteunende kleur | 1.07B 74% NTSC |
| gewicht | 2.51Kgs (Typ.) |
| frame rate | 60Hz |
| d-ic detail | COF Built-in 12 source chips |
| interface-type | V-by-One 8 lane , 51 pins Connector |
| stroomvoorziening | 12.0V (Typ.) |
| omgeving | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | T550QVR08.4 CELL |
| type | a-Si TFT-LCD , CELL |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 1219.6(H)×691.9(V) ×1.32(D) mm |
| behandeling | Antiglare (Haze 2%), Hard coating (3H) |
| contrast ratio | 3500:1 (Typ.) (TM) |
| reactietijd | 8 (Typ.)(G to G) |
| bedrijfsmodus | AMVA3, Normally Black, Transmissive |
| doorlaatbaarheid | 5.1% (Typ.)(with Polarizer) |
| lichtbron | No B/L |
| ontworpen voor | TV Sets |
| aanraakpaneel | Without |
