| Onderdeel nummer | STCG057QVLAD-G00 |
| Merk | Kyocera |
| Maat | 5.7 |
| Sollicitatie | Industrial |
| Oplossing | 320×240 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | Parallel |
| fabrikant | Kyocera |
| modelnaam | STCG057QVLAD-G00 |
| scherm grootte | 5.7 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 320(RGB)×240 (QVGA) 70PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 115.2 × 86.4 (H×V) |
| overzicht (mm) | - |
| bezel gebied (mm) | - |
| behandeling | Glare (Haze 0%) |
| luminantie | - |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥5) |
| antwoord | 10/25 (Typ.)(Tr/Td) ms |
| goed zicht op | - |
| werk modus | TN, Normally White, Transmissive |
| kleuren diepte | 262K |
| tegenlicht | WLED |
| massa | - |
| gebruikt voor | Industrial |
| vernieuwingsfrequentie | - |
| touch screen | 4-wire Resistive Touch |
| signaal type | Parallel RGB (1 ch, 6-bit) |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| DMF-50840NB-FW | Kyocera | 5.7 | 320×240 |
| EL320.240.36 | Lumineq | 5.7 | 320×240 |
| ER0570B2NC6 | EDT | 5.7 | 320×240 |
| KCG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| KCG057QV1DB-G77 | Kyocera | 5.7 | 320×240 |
| KG057QV1CA-G03 | Kyocera | 5.7 | 320×240 |
| LQ057V3DG01 | SHARP | 5.7 | 640×480 |
| TCG057QVLAC-G00 | Kyocera | 5.7 | 320×240 |
