| Onderdeel nummer | R140NWF5 RC |
| Merk | IVO |
| Maat | 14.0 |
| Sollicitatie | Laptop |
| Oplossing | 1920×1080 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | eDP |
| paneel merk | IVO |
| paneel grootte | 14.0" |
| oplossing | 1920(RGB)×1080, FHD, 157PPI |
| weergavegebied | 309.31(W)×173.99(H) mm |
| omtrek grootte | 315.81(W)×197.55(H) ×3(D) mm |
| helderheid | 250 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 262K 45% NTSC |
| frequentie | 60Hz |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| signaal interface | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneelmodel | R140NWF5 RC (IVO057D) |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | IPS, Normally Black, Transmissive |
| reactietijd | 30 (Typ.)(Tr+Td) |
| soort lamp | WLED , 15K hours , With LED Driver |
| touch screen | On-Cell Touch |
| sollicitatie | Laptop |
| B140RTN02.3 | AUO | 14.0 | 1600×900 |
| HB140WX1-301 | BOE | 14.0 | 1366×768 |
| LP140WD2-TLB1 | LG Display | 14.0 | 1600×900 |
| LP140WF1-SPJ1 | LG Display | 14.0 | 1920×1080 |
| LP140WH4-TLD1 | LG Display | 14.0 | 1366×768 |
| LTN140AT02-C02 | Samsung | 14.0 | 1366×768 |
| LTN140AT20-T01 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-T01 | Samsung | 14.0 | 1366×768 |
| N140BGE-L21 | Innolux | 14.0 | 1366×768 |
| N140BGE-LB2 | Innolux | 14.0 | 1366×768 |
