| Onderdeel nummer | QV101WUB-N80 |
| Merk | BOE |
| Maat | 10.1 |
| Sollicitatie | Industrial |
| Oplossing | 1920×1200 |
| Samenstelling | CELL , a-Si TFT-LC |
| Helderheid | |
| CR | 900:1 |
| Kleuren | 16.7M |
| Tegenlicht | No |
| Koppel | |
| fabrikant | BOE |
| scherm grootte | 10.1 inch |
| pixel nummer | 1920(RGB)×1200 (WUXGA) 224PPI |
| actief gebied (mm) | 216.806 × 135.504 (H×V) |
| bezel gebied (mm) | - |
| luminantie | 0 (cd/m²) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| glas dikte | - |
| kleuren diepte | 16.7M 72% NTSC |
| massa | - |
| vernieuwingsfrequentie | 60Hz |
| modelnaam | QV101WUB-N80 |
| scherm type | CELL , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 221.81 × 145.5 (H×V×D) |
| behandeling | Hard coating |
| contrast ratio | 900 : 1 (Typ.) (TM) |
| werk modus | ADS, Normally Black, Transmissive |
| antwoord | 30 (Typ.)(Tr+Td) ms |
| doorlaatbaarheid | 3.85% (Typ.)(with Polarizer) |
| tegenlicht | No B/L |
| gebruikt voor | Industrial |
| touch screen | Without |
