| Onderdeel nummer | QT156WHM-N50 |
| Merk | BOE |
| Maat | 15.6 |
| Sollicitatie | Laptop Printer Home |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | LVDS |
| paneel merk | BOE |
| paneel grootte | 15.6" |
| oplossing | 1366(RGB)×768, WXGA, 100PPI |
| weergavegebied | 344.232(W)×193.536(H) mm |
| helderheid | 200 cd/m² (Typ.) |
| kijk hoek | 45/45/20/40 (Typ.)(CR≥10) |
| beste zicht op | 6 o'clock |
| kleuren weergeven | 262K 45% NTSC |
| frequentie | 60Hz |
| vorm stijl | Wedge (PCBA Bent, T≥5.2mm) |
| signaal interface | LVDS (1 ch, 6-bit) , 40 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneelmodel | QT156WHM-N50 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 12 (Typ.)(Tr+Td) |
| soort lamp | WLED , 15K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Laptop Printer Home Appliance |
