| Onderdeel nummer | PV190E0M-N10 |
| Merk | BOE |
| Maat | 19.0 |
| Sollicitatie | Industrial |
| Oplossing | 1280×1024 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | |
| fabrikant | BOE |
| scherm grootte | 19.0 inch |
| pixel nummer | 1280(RGB)×1024 (SXGA) 86PPI |
| actief gebied (mm) | 374.784 × 299.827 (H×V) |
| bezel gebied (mm) | 379 × 303 (H×V) |
| luminantie | 400 (Typ.)(cd/m²) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M 73% NTSC |
| massa | 1.95Kgs (Typ.) |
| vernieuwingsfrequentie | 60Hz |
| modelnaam | PV190E0M-N10 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 396 × 324 × 12.13 (H×V×D) |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| werk modus | ADS, Normally Black, Transmissive |
| antwoord | 14 (Typ.)(G to G) ms |
| tegenlicht | WLED , 50K hours , No Driver |
| gebruikt voor | Industrial |
| touch screen | Without |
