| Onderdeel nummer | PT156WHM-N10 |
| Merk | BOE |
| Maat | 15.6 |
| Sollicitatie | Industrial |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | 10S4P |
| Koppel | |
| paneel merk | BOE |
| paneel grootte | 15.6" |
| oplossing | 1366(RGB)×768, WXGA, 100PPI |
| weergavegebied | 344.23(W)×193.54(H) mm |
| omtrek grootte | 359.5(W)×223.8(H) ×3.2(D) mm |
| helderheid | 400 cd/m² (Typ.) |
| kijk hoek | 45/45/20/40 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K 45% NTSC |
| frequentie | 60Hz |
| gewicht | 370g (Max.) |
| paneelmodel | PT156WHM-N10 (BOE06A5) |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | Antiglare |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 12 (Typ.)(Tr+Td) |
| soort lamp | 10S4P WLED , 30K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Industrial |
