| Onderdeel nummer | PJ050IA-05L |
| Merk | Innolux |
| Maat | 5.0 |
| Sollicitatie | Mobile Phone |
| Oplossing | 720×1280 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 6S2P |
| Koppel | MIPI |
| fabrikant | Innolux |
| modelnaam | PJ050IA-05L |
| scherm grootte | 5.0 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 720(RGB)×1280 (WXGA) 294PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 62.1 × 110.4 (H×V) |
| overzicht (mm) | 64.18 × 117.56 × 1.42 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Glare (Haze 0%), Hard coating (3H) |
| luminantie | 450 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | AAS, Normally Black, Transmissive |
| kleuren diepte | 16.7M 72% NTSC |
| tegenlicht | 6S2P WLED , No Driver |
| massa | 17.2g |
| gebruikt voor | Mobile Phone |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | MIPI (4 data lanes) , 30 pins Connector |
| spanningsvoorziening | 1.8/5.4/-5.4V (Typ.)(VDDI/AVDD/AVEE) |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
