| Onderdeel nummer | P101DEA-AZ0 |
| Merk | Innolux |
| Maat | 10.1 |
| Sollicitatie | Pad & Tablet |
| Oplossing | 800×1280 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 4 |
| Koppel | MIPI |
| fabrikant | Innolux |
| modelnaam | P101DEA-AZ0 |
| scherm grootte | 10.1 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 800(RGB)×1280 (WXGA) 150PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 135.36 × 216.576 (H×V) |
| overzicht (mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Glare (Haze 0%), Hard coating |
| luminantie | 500 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| kijk hoek | 80/80/80/80 (Min.)(CR≥10) |
| antwoord | 35 (Max.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | AAS, Normally Black, Transmissive |
| kleuren diepte | 16.7M 60% NTSC |
| tegenlicht | 4 strings WLED , 15K hours , No Driver |
| massa | 175g (Max.) |
| gebruikt voor | Pad & Tablet |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | MIPI (4 data lanes) , Connector 40 pins |
| spanningsvoorziening | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| max. waarderingen | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
