| Onderdeel nummer | P0650VGF1MA10 |
| Merk | TIANMA |
| Maat | 6.5 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 640×480 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 900:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | 6S2P |
| Koppel | LVDS |
| paneel merk | TIANMA |
| paneelmodel | P0650VGF1MA10 |
| paneel grootte | 6.5" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 640(RGB)×480, VGA, 122PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 132.48(W)×99.36(H) mm |
| omlijsting openen | 135.48(W)×102.36(H) mm |
| omtrek grootte | 153(W)×118(H) ×11.2(D) mm |
| oppervlak | Antiglare |
| helderheid | 800 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | SFT, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kleuren weergeven | 262K/16.7M 70% NTSC |
| soort lamp | 6S2P WLED , 70K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| paneel gewicht | TBD |
| sollicitatie | Industrial Outdoor High Brightness Automotive Display |
| signaal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
