| Onderdeel nummer | NV156FHM-NY8 |
| Merk | BOE |
| Maat | 15.6 |
| Sollicitatie | Laptop Gaming |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 1.06B |
| Tegenlicht | 10S5P |
| Koppel | eDP |
| fabrikant | BOE |
| scherm grootte | 15.6 inch |
| pixel nummer | 1920(RGB)×1080 (FHD) 141PPI |
| actief gebied (mm) | 344.16 × 193.59 (H×V) |
| bezel gebied (mm) | - |
| luminantie | 300 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 1.06B 100% sRGB |
| omlijnde vorm | Slim (PCBA Flat, T≤3.2mm) |
| vernieuwingsfrequentie | 165Hz |
| signaal type | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| modelnaam | NV156FHM-NY8 (BOE0998) |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 350.66 × 214.75 × 2.6 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| antwoord | 9 (Typ.)(Tr+Td); 8 (Typ.)(G to G) ms |
| werk modus | HADS, Normally Black, Transmissive |
| tegenlicht | 10S5P WLED , 15K hours , With LED Driver |
| gebruikt voor | Laptop Gaming |
| touch screen | Without |
