| Onderdeel nummer | NV140DQM-N51 |
| Merk | BOE |
| Maat | 14.1 |
| Sollicitatie | Laptop |
| Oplossing | 1920×550 |
| Samenstelling | a-Si TFT-LCD, LCM |
| Helderheid | |
| CR | 1200:1 |
| Kleuren | 16.7M |
| Tegenlicht | 10S6P |
| Koppel | eDP |
| paneel merk | BOE |
| paneelmodel | NV140DQM-N51 (BOE0922) |
| paneel grootte | 14.1" |
| paneel type | a-Si TFT-LCD, LCM |
| oplossing | 1920(RGB)×550, 141PPI |
| pixel formaat | RGB Vertical Stripe |
| weergavegebied | 344.218(W)×98.604(H) mm |
| omlijsting openen | - |
| omtrek grootte | 350.52(W)×118.65(H) ×2.5(D) mm |
| oppervlak | Antiglare (Haze 25%), Hard coating (3H) |
| helderheid | 400 cd/m² (Typ.) |
| contrast ratio | 1200:1 (Typ.) (TM) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| weergavemodus | ADS, Normally Black, Transmissive |
| beste zicht op | Symmetry |
| reactietijd | 30 (Typ.)(Tr+Td) |
| kleuren weergeven | 16.7M 100% sRGB |
| soort lamp | 10S6P WLED , 15K hours , With LED Driver |
| frequentie | 60Hz |
| touch screen | Without |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| sollicitatie | Laptop |
| signaal interface | eDP (2 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 30 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 65 °C |
| B141EW03 V3 | AUO | 14.1 | 1280×800 |
| B141EW05 V4 | AUO | 14.1 | 1280×800 |
| B141XG08 V3 | AUO | 14.1 | 1024×768 |
| LP141WX3-TLA3 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLP2 | LG Display | 14.1 | 1280×800 |
| LTN141AT05-G03 | Samsung | 14.1 | 1280×800 |
| LTN141WD-L05 | Samsung | 14.1 | 1440×900 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
| N141I6-D11 | Innolux | 14.1 | 1280×800 |
| QD14TL01 Rev.04 | QDI | 14.1 | 1280×800 |
