| Onderdeel nummer | NV116WHM-T1C |
| Merk | BOE |
| Maat | 11.6 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD , Assem |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K |
| Tegenlicht | 8S3P |
| Koppel | eDP |
| paneel merk | BOE |
| paneel grootte | 11.6" |
| oplossing | 1366(RGB)×768, WXGA, 135PPI |
| weergavegebied | 256.125(W)×144(H) mm |
| omtrek grootte | 284.85(W)×189.84(H) ×4.2(D) mm |
| helderheid | 220 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 262K 50% NTSC |
| frequentie | 60Hz |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| signaal interface | eDP (2 Lanes) , 40 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| paneelmodel | NV116WHM-T1C (BOE08B4) |
| paneel type | a-Si TFT-LCD , Assembly |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | Hard coating (7H) |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | - |
| reactietijd | 30 (Typ.)(Tr+Td) |
| soort lamp | 8S3P WLED , 15K hours , With LED Driver |
| touch screen | On-Cell Touch |
| sollicitatie | Laptop |
| A116XW02 V0 | AUO | 11.6 | 1366×768 |
| B116HAT03.1 | AUO | 11.6 | 1920×1080 |
| LP116WF1-SPA1 | LG Display | 11.6 | 1920×1080 |
| LP116WH6-SPA2 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R7 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116B6-L07 | Innolux | 11.6 | 1366×768 |
| N116BGE-LB1 | Innolux | 11.6 | 1366×768 |
| N116HSE-EA2 | Innolux | 11.6 | 1920×1080 |
| N116HSE-EJ1 | Innolux | 11.6 | 1920×1080 |
