| Onderdeel nummer | NV116WHM-A23 |
| Merk | BOE |
| Maat | 11.6 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD , Assem |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K |
| Tegenlicht | 6S4P |
| Koppel | |
| paneel merk | BOE |
| paneel grootte | 11.6" |
| oplossing | 1366(RGB)×768, WXGA, 135PPI |
| weergavegebied | 256.125(W)×144(H) mm |
| omtrek grootte | 287.7(W)×185.6(H) ×4.05(D) mm |
| helderheid | 200 cd/m² (Typ.) |
| kijk hoek | 80/80/80/80 (Min.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 262K 50% NTSC |
| frequentie | 60Hz |
| vorm stijl | Slim (PCBA Flat, T≤3.2mm) |
| paneelmodel | NV116WHM-A23 (BOE0744) |
| paneel type | a-Si TFT-LCD , Assembly |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | Anti-Scatter, Hard coating (7H) |
| contrast ratio | 800:1 (Typ.) (TM) |
| weergavemodus | - |
| reactietijd | 30 (Typ.)(Tr+Td) |
| soort lamp | 6S4P WLED , 15K hours , With LED Driver |
| touch screen | PCAP, Optical Bonding |
| sollicitatie | Laptop |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116BGE-EB2 Rec.C3 | Innolux | 11.6 | 1366×768 |
| N116BGE-L42 | Innolux | 11.6 | 1366×768 |
