| Onderdeel nummer | NV101WUM-N52 |
| Merk | BOE |
| Maat | 10.1 |
| Sollicitatie | Pad & Tablet |
| Oplossing | 1200×1920 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | MIPI |
| fabrikant | BOE |
| scherm grootte | 10.1 inch |
| pixel nummer | 1200(RGB)×1920 (WUXGA) 225PPI |
| actief gebied (mm) | 135.36 × 216.576 (H×V) |
| luminantie | 400 cd/m² (Typ.) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M 68% NTSC |
| massa | 132g (Typ.) |
| vernieuwingsfrequentie | 60Hz |
| signaal type | MIPI (4 data lanes) , 42 pins Connector |
| spanningsvoorziening | 1.8/3.3V (Typ.)(VDD1/VDD3) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| modelnaam | NV101WUM-N52 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 141.56 × 228.226 × 4.2 (H×V×D) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| antwoord | 35 (Max.)(Tr+Td) ms |
| werk modus | ADS, Normally Black, Transmissive |
| tegenlicht | WLED , 15K hours , No Driver |
| gebruikt voor | Pad & Tablet |
| touch screen | Without |
