| Onderdeel nummer | NT133WHM-N23 |
| Merk | BOE |
| Maat | 13.3 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | 9S4P |
| Koppel | eDP |
| paneel merk | BOE |
| paneel grootte | 13.3" |
| oplossing | 1366(RGB)×768, WXGA, 118PPI |
| weergavegebied | 293.42(W)×164.97(H) mm |
| omtrek grootte | 306.3(W)×188.75(H) ×3.6(D) mm |
| helderheid | 220 cd/m² (Typ.) |
| kijk hoek | 45/45/20/40 (Typ.)(CR≥10) |
| beste zicht op | 6 o'clock |
| kleuren weergeven | 262K 48% NTSC |
| frequentie | 60Hz |
| vorm stijl | Flat (PCBA Flat, T3.4~4.0mm) |
| signaal interface | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| ingangsspanning | 3.3V (Typ.) |
| omgeving | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| paneelmodel | NT133WHM-N23 (BOE06D8) |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | Antiglare |
| contrast ratio | 500:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 12 (Typ.)(Tr+Td) |
| soort lamp | 9S4P WLED , 15K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Laptop |
| B133XW07 V2 | AUO | 13.3 | 1366×768 |
| LP133WH2-TLA3 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL2 | LG Display | 13.3 | 1366×768 |
| LP133WP1-TJA7 | LG Display | 13.3 | 1440×900 |
| LTN133AT05-S02 | Samsung | 13.3 | 1280×800 |
| M133NWF2 R0 | IVO | 13.3 | 1920×1080 |
| M133NWN1 R1 | IVO | 13.3 | 1366×768 |
| N133B6-L02 | Innolux | 13.3 | 1366×768 |
| N133BGE-LB1 | Innolux | 13.3 | 1366×768 |
| TM133XG-02L07A | SANYO | 13.3 | 1024×768 |
