| Onderdeel nummer | NT116WHM-N23 |
| Merk | BOE |
| Maat | 11.6 |
| Sollicitatie | Laptop |
| Oplossing | 1366×768 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 500:1 |
| Kleuren | 262K |
| Tegenlicht | 8S3P |
| Koppel | |
| fabrikant | BOE |
| modelnaam | NT116WHM-N23 (BOE066B) |
| scherm grootte | 11.6 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1366(RGB)×768 (WXGA) 135PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 256.125 × 144 (H×V) |
| overzicht (mm) | 268 × 172.98 × 3 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Glare (Haze 0%), Hard coating (3H) |
| luminantie | 220 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| kijk hoek | 45/45/20/40 (Typ.)(CR≥10) |
| antwoord | 12 (Typ.)(Tr+Td) ms |
| goed zicht op | 6 o'clock |
| werk modus | TN, Normally White, Transmissive |
| kleuren diepte | 262K 45% NTSC |
| tegenlicht | 8S3P WLED , 15K hours , With LED Driver |
| omlijnde vorm | Slim (PCBA Flat, T≤3.2mm) |
| gebruikt voor | Laptop |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XW03 V0 | AUO | 11.6 | 1366×768 |
| LP116WH4-SLN2 | LG Display | 11.6 | 1366×768 |
| N116B6-L02 | Innolux | 11.6 | 1366×768 |
| N116BGE-L11 | Innolux | 11.6 | 1366×768 |
| NT116WHM-N11 | BOE | 11.6 | 1366×768 |
| NT116WHM-N21 | BOE | 11.6 | 1366×768 |
| NT116WHM-N22 | BOE | 11.6 | 1366×768 |
| NT116WHM-N31 | BOE | 11.6 | 1366×768 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
