| Onderdeel nummer | NL8048BC21-03F |
| Merk | NLT |
| Maat | 8.0 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 800×480 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| merk | NLT |
| diagonale maat | 8.0 inch |
| pixel formaat | 800(RGB)×480 [WVGA] 116PPI |
| actief gebied | 174(H)×104.4(V) mm |
| bezel gebied | - |
| luminantie | 1000 cd/m² (Typ.) |
| richting bekijken | Symmetry |
| kijk hoek | 88/88/88/88 (Typ.)(CR≥10) |
| ondersteunende kleur | 262K/16.7M 72% NTSC |
| gewicht | 225g |
| frame rate | 60Hz |
| interface-type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| stroomvoorziening | 3.3V (Typ.) |
| omgeving | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
| model | NL8048BC21-03F |
| type | a-Si TFT-LCD , LCM |
| configuratie | RGB Vertical Stripe |
| omtrek afm. | 192(H)×122(V) mm |
| behandeling | Antiglare |
| contrast ratio | 1000:1 (Typ.) (TM) |
| reactietijd | 20 (Typ.)(Tr+Td) |
| bedrijfsmodus | SFT, Normally Black, Transmissive |
| lichtbron | WLED |
| ontworpen voor | Industrial Outdoor High Brightness |
| aanraakpaneel | Without |
