| Onderdeel nummer | NL6448AC33-A1D |
| Merk | NLT |
| Maat | 10.4 |
| Sollicitatie | Industrial |
| Oplossing | 640×480 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 900:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | |
| fabrikant | NLT |
| modelnaam | NL6448AC33-A1D |
| scherm grootte | 10.4 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 640(RGB)×480 (VGA) 76PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 211.2 × 158.4 (H×V) |
| overzicht (mm) | 227.3 × 177.5 × 9.8 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare |
| luminantie | 370 cd/m² (Typ.) |
| contrast ratio | 900 : 1 (Typ.) (TM) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| antwoord | 18 (Typ.)(Tr+Td) ms |
| goed zicht op | - |
| werk modus | TN, Normally White, Transmissive |
| kleuren diepte | 262K |
| tegenlicht | WLED , 100K hours , With LED Driver |
| massa | 380g (Max.) |
| gebruikt voor | Industrial |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| NL6448AC33-05 | NLT | 10.4 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-24 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
