| Onderdeel nummer | NL6448AC33-A0D |
| Merk | NLT |
| Maat | 10.4 |
| Sollicitatie | Industrial |
| Oplossing | 640×480 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 900:1 |
| Kleuren | 262K |
| Tegenlicht | WLED |
| Koppel | CMOS |
| paneel merk | NLT |
| paneel grootte | 10.4" |
| oplossing | 640(RGB)×480, VGA, 76PPI |
| weergavegebied | 211.2(W)×158.4(H) mm |
| omtrek grootte | 246.5(W)×179.4(H) ×10(D) mm |
| helderheid | 500 cd/m² (Typ.) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| beste zicht op | - |
| kleuren weergeven | 262K 40% NTSC |
| frequentie | 60Hz |
| paneel gewicht | 390/435g (Typ./Max.) |
| signaal interface | CMOS (1 ch, 6-bit) , 31 pins Connector |
| ingangsspanning | 3.3/5.0V (Typ.) |
| omgeving | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| paneelmodel | NL6448AC33-A0D |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 900:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 3/15 (Typ.)(Tr/Td) |
| soort lamp | WLED , 100K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Industrial |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| NL6448AC33-05 | NLT | 10.4 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-18A | NLT | 10.4 | 640×480 |
| NL6448AC33-24 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
