| Onderdeel nummer | NL3224AC35-09 |
| Merk | NEC |
| Maat | 5.5 |
| Sollicitatie | Industrial |
| Oplossing | 320×240 |
| Samenstelling | a-Si TFT-LCD , LCM |
| Helderheid | |
| CR | 400:1 |
| Kleuren | 262K |
| Tegenlicht | - |
| Koppel | |
| paneel merk | NEC |
| paneel grootte | 5.5" |
| oplossing | 320(RGB)×240, QVGA, 72PPI |
| weergavegebied | 111.36(W)×83.52(H) mm |
| helderheid | - |
| kijk hoek | - |
| beste zicht op | - |
| kleuren weergeven | 262K |
| frequentie | 60Hz |
| gewicht | - |
| paneelmodel | NL3224AC35-09 |
| paneel type | a-Si TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| contrast ratio | 400:1 (Typ.) (TM) |
| weergavemodus | TN, Normally White, Transmissive |
| reactietijd | 5/25 (Typ.)(Tr/Td) |
| soort lamp | |
| touch screen | Without |
| sollicitatie | Industrial |
