| Onderdeel nummer | NL192108BC18-06F |
| Merk | NLT |
| Maat | 15.6 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 750:1 |
| Kleuren | 16.7M |
| Tegenlicht | 4 |
| Koppel | eDP |
| fabrikant | NLT |
| modelnaam | NL192108BC18-06F |
| scherm grootte | 15.6 inch |
| scherm type | LCM , a-Si TFT-LCD |
| pixel nummer | 1920(RGB)×1080 (FHD) 141PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 344.16 × 193.59 (H×V) |
| overzicht (mm) | 363.8 × 215.9 × 16.2 (H×V×D) |
| bezel gebied (mm) | 347.55 × 196.75 (H×V) |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 1500 cd/m² (Typ.) |
| contrast ratio | 750 : 1 (Typ.) (TM) |
| kijk hoek | 88/88/88/88 (Typ.)(CR≥10) |
| antwoord | 15/15 (Typ.)(Tr/Td) ms |
| goed zicht op | Symmetry |
| werk modus | UA-SFT, Normally Black, Transmissive |
| kleuren diepte | 16.7M 40% NTSC |
| tegenlicht | 4 strings WLED , 50K hours , No Driver |
| massa | 1.05/1.15Kgs (Typ./Max.) |
| gebruikt voor | Industrial Outdoor High Brightness |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | eDP (2 Lanes) , HBR1 (2.7G/lane) , 40 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -40 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
