| Onderdeel nummer | NL192108AC21-04 |
| Merk | NLT |
| Maat | 18.5 |
| Sollicitatie | Industrial |
| Oplossing | 1920×1080 |
| Samenstelling | LCM , a-Si TFT-LCD |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | WLED |
| Koppel | LVDS |
| fabrikant | NLT |
| scherm grootte | 18.5 inch |
| pixel nummer | 1920(RGB)×1080 (FHD) 119PPI |
| actief gebied (mm) | 408.96 × 230.04 (H×V) |
| bezel gebied (mm) | 413.4 × 234.0 (H×V) |
| luminantie | 400 cd/m² (Typ.) |
| kijk hoek | 88/88/88/88 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 16.7M 72% NTSC |
| massa | 1.55/1.70Kgs (Typ./Max.) |
| vernieuwingsfrequentie | 60Hz |
| signaal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spanningsvoorziening | 5.0V (Typ.) |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| modelnaam | NL192108AC21-04 |
| scherm type | LCM , a-Si TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 430.4 × 254.6 × 14 (H×V×D) |
| behandeling | Antiglare, Hard coating (3H) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| antwoord | 12/13 (Typ.)(Tr/Td) ms |
| werk modus | UA-SFT, Normally Black, Transmissive |
| tegenlicht | WLED , 50K hours , With LED Driver |
| gebruikt voor | Industrial |
| touch screen | Without |
