| Onderdeel nummer | NL12880BC20-25F |
| Merk | NLT |
| Maat | 12.1 |
| Sollicitatie | Industrial Outdoor H |
| Oplossing | 1280×800 |
| Samenstelling | LCM, a-Si TFT-LCD |
| Helderheid | |
| CR | 800:1 |
| Kleuren | 262K/16.7M |
| Tegenlicht | 3 |
| Koppel | LVDS |
| fabrikant | NLT |
| modelnaam | NL12880BC20-25F |
| scherm grootte | 12.1 inch |
| scherm type | LCM, a-Si TFT-LCD |
| pixel nummer | 1280(RGB)×800 (WXGA) 124PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 261.12 × 163.2 (H×V) |
| overzicht (mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| bezel gebied (mm) | 266.1 × 168.2 (H×V) |
| behandeling | Antiglare, Hard coating (3H) |
| luminantie | 1600 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| kijk hoek | 80/80/80/80 (Typ.)(CR≥10) |
| antwoord | 15 (Typ.)(Tr+Td) ms |
| goed zicht op | 6 o'clock |
| werk modus | TN, Normally White, Transmissive |
| kleuren diepte | 262K/16.7M 50% NTSC |
| tegenlicht | 3 strings WLED , 60K hours , No Driver |
| massa | 470g (Typ.) |
| gebruikt voor | Industrial Outdoor High Brightness |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
