| Onderdeel nummer | NE156QUM-N55 |
| Merk | BOE |
| Maat | 15.6 |
| Sollicitatie | Laptop |
| Oplossing | 3840×2160 |
| Samenstelling | LCM , Oxide TFT-LC |
| Helderheid | |
| CR | 1400:1 |
| Kleuren | 1.07B |
| Tegenlicht | 12S6P |
| Koppel | |
| fabrikant | BOE |
| scherm grootte | 15.6 inch |
| pixel nummer | 3840(RGB)×2160 (UHD) 283PPI |
| actief gebied (mm) | 344.218 × 193.622 (H×V) |
| bezel gebied (mm) | - |
| luminantie | 500 (Typ.)(cd/m²) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| goed zicht op | Symmetry |
| kleuren diepte | 1.07B 100% sRGB |
| omlijnde vorm | Slim (PCBA Bent, T≤3.0mm) |
| vernieuwingsfrequentie | 60Hz |
| modelnaam | NE156QUM-N55 (BOE084B) |
| scherm type | LCM , Oxide TFT-LCD |
| regeling | RGB Vertical Stripe |
| overzicht (mm) | 350.66 × 205.84 × 4.6 (H×V×D) |
| behandeling | Glare (Haze 0%), Hard coating (3H) |
| contrast ratio | 1400 : 1 (Typ.) (TM) |
| werk modus | ADS, Normally Black, Transmissive |
| antwoord | 25 (Typ.)(Tr+Td) ms |
| tegenlicht | 12S6P WLED , 20K hours , With LED Driver |
| gebruikt voor | Laptop |
| touch screen | Without |
| B156HAN01.2 | AUO | 15.6 | 1920×1080 |
| B156HB01 V0 | AUO | 15.6 | 1920×1080 |
| B156HW01 V1 | AUO | 15.6 | 1920×1080 |
| B156XW03 V1 | AUO | 15.6 | 1366×768 |
| G156HTN02.1 | AUO | 15.6 | 1920×1080 |
| LTN156AT09-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT34-D01 | Samsung | 15.6 | 1366×768 |
| N156BGE-EB1 | Innolux | 15.6 | 1366×768 |
| N156HGE-L11 | Innolux | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
