| Onderdeel nummer | NE140FHM-N46 |
| Merk | BOE |
| Maat | 14.0 |
| Sollicitatie | Laptop |
| Oplossing | 1920×1080 |
| Samenstelling | Oxide TFT-LCD , LCM |
| Helderheid | |
| CR | 1500:1 |
| Kleuren | 16.7M |
| Tegenlicht | 10S6P |
| Koppel | |
| paneel merk | BOE |
| paneel grootte | 14.0" |
| oplossing | 1920(RGB)×1080, FHD, 157PPI |
| weergavegebied | 309.312(W)×173.988(H) mm |
| omtrek grootte | 315.81(W)×186.26(H) ×4.4(D) mm |
| helderheid | 400 cd/m² (Typ.) |
| kijk hoek | 85/85/85/85 (Typ.)(CR≥10) |
| beste zicht op | Symmetry |
| kleuren weergeven | 16.7M 100% sRGB |
| frequentie | 60Hz |
| vorm stijl | Slim (PCBA Bent, T≤3.0mm) |
| paneelmodel | NE140FHM-N46 (BOE091B) |
| paneel type | Oxide TFT-LCD , LCM |
| pixel formaat | RGB Vertical Stripe |
| omlijsting openen | - |
| oppervlak | Antiglare, Hard coating (3H) |
| contrast ratio | 1500:1 (Typ.) (TM) |
| weergavemodus | ADS, Normally Black, Transmissive |
| reactietijd | 30 (Typ.)(Tr+Td) |
| soort lamp | 10S6P WLED , 15K hours , With LED Driver |
| touch screen | Without |
| sollicitatie | Laptop |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| HB140WX1-300 | BOE | 14.0 | 1366×768 |
| LP140WH4-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLD1 | LG Display | 14.0 | 1366×768 |
| LTN140AT26-L01 | Samsung | 14.0 | 1366×768 |
| LTN140KT03 | Samsung | 14.0 | 1600×900 |
| N140B6-D11 | Innolux | 14.0 | 1366×768 |
| N140BGE-L21 | Innolux | 14.0 | 1366×768 |
| N140BGE-L31 | Innolux | 14.0 | 1366×768 |
| N140BGE-L41 | Innolux | 14.0 | 1366×768 |
