| Onderdeel nummer | NE133QUM-N42 |
| Merk | BOE |
| Maat | 13.3 |
| Sollicitatie | Laptop |
| Oplossing | 3840×2160 |
| Samenstelling | LCM , Oxide TFT-LC |
| Helderheid | |
| CR | 1000:1 |
| Kleuren | 16.7M |
| Tegenlicht | 9S5P |
| Koppel | eDP |
| fabrikant | BOE |
| modelnaam | NE133QUM-N42 (BOE08CA) |
| scherm grootte | 13.3 inch |
| scherm type | LCM , Oxide TFT-LCD |
| pixel nummer | 3840(RGB)×2160 (UHD) 332PPI |
| regeling | RGB Vertical Stripe |
| actief gebied (mm) | 293.76 × 165.24 (H×V) |
| overzicht (mm) | 298.76 × 176.42 × 4.6 (H×V×D) |
| bezel gebied (mm) | - |
| behandeling | Antiglare (Haze 25%), Hard coating (3H) |
| luminantie | 300 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| kijk hoek | 89/89/89/89 (Typ.)(CR≥10) |
| antwoord | 30 (Typ.)(Tr+Td) ms |
| goed zicht op | Symmetry |
| werk modus | ADS, Normally Black, Transmissive |
| kleuren diepte | 16.7M 100% sRGB |
| tegenlicht | 9S5P WLED , 15K hours , With LED Driver |
| omlijnde vorm | Slim (PCBA Bent, T≤3.0mm) |
| gebruikt voor | Laptop |
| vernieuwingsfrequentie | 60Hz |
| touch screen | Without |
| signaal type | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| spanningsvoorziening | 3.3V (Typ.) |
| max. waarderingen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B133XW03 V4 | AUO | 13.3 | 1366×768 |
| HN133WU3-100 | BOE | 13.3 | 1920×1080 |
| LP133WD2-SLB1 | LG Display | 13.3 | 1600×900 |
| LP133WH2-TLB2 | LG Display | 13.3 | 1366×768 |
| LP133WQ1-SJA1 | LG Display | 13.3 | 2560×1600 |
| LTN133W1-L01 | Samsung | 13.3 | 1280×800 |
| M133NWF2 R0 | IVO | 13.3 | 1920×1080 |
| N133BGE-EAB | Innolux | 13.3 | 1366×768 |
| TM133XG-02L07A | SANYO | 13.3 | 1024×768 |
| VVX13F009G10 | Panasonic | 13.3 | 1920×1080 |
